John's 2dof scn5 (playseat)

Discussion in 'DIY Motion Simulator Projects' started by johnfatboy, Sep 18, 2009.

  1. johnfatboy

    johnfatboy New Member

    Joined:
    Sep 6, 2009
    Messages:
    34
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
    Ok, well last night i started on my project. Came from the local electronics store with my zener diodes and resistors, took off the rear part of my playseat, dissasembled it and headed for the garage. I have been saving metal from various places, packrat johnny :D made with what i have so far work :clap:

    here is what i have done so far... i am using as a pivot a honda inner tie rod 8)

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]


    note, i am removing the left and right plate on the playseat...its on now just for measuring the height and the positioning of the seat.... i am bolting the lower attachment to the frame..therefore being able to use the pedal and wheel attachment with the adjust-ability it originally had.
  2. Ads Master

    Ads Master

    Balance:
    Coins
    Ratings:
    +0 / 0 / -0
  3. jakob

    jakob New Member

    Joined:
    Sep 4, 2009
    Messages:
    83
    Location:
    Frankfurt
    Balance:
    313Coins
    Ratings:
    +3 / 0 / -0
    One littlesuggestion for improvement: Why don't you send me the two SCN5 actuators and drive your sim with the V-Twin from that nice Fatboy? Driving it should feel like a bullride on acid.

    Sorry for OT :blush:
  4. johnfatboy

    johnfatboy New Member

    Joined:
    Sep 6, 2009
    Messages:
    34
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
  5. johnfatboy

    johnfatboy New Member

    Joined:
    Sep 6, 2009
    Messages:
    34
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
    :) second night and brought home a couple of stabalizer links from a Odyssey i had lying around to keep the cockpit from rotating.
    Finally got it almost all done, had to, need my playseat to get back to some racing :D
    now all that is left is the placement of the actuators on the rear bar when i finally open up my piggy bank, and the attachment of the playseat slider, so i can adjust my pedals and wheel as needed.
    here are a few pics and a video.




    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    [​IMG]
  6. ledfoot

    ledfoot Member

    Joined:
    Sep 9, 2009
    Messages:
    369
    Occupation:
    IT Manager
    Location:
    Toronto, Canada
    Balance:
    20Coins
    Ratings:
    +2 / 0 / -0
    Nice work so far. I did a playseat conversion as well but I just used the front end and ajust using the t-slot framing. Not as easy as before but I hardly need to adjust.

    ....Mike
  7. ledfoot

    ledfoot Member

    Joined:
    Sep 9, 2009
    Messages:
    369
    Occupation:
    IT Manager
    Location:
    Toronto, Canada
    Balance:
    20Coins
    Ratings:
    +2 / 0 / -0
    Any more progress on this John?
  8. johnfatboy

    johnfatboy New Member

    Joined:
    Sep 6, 2009
    Messages:
    34
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
    just trimmed off some excess metal, went to spray paint it, started a few strokes and then left it, last thing i need is paint on the bike :blush: . Waiting on the power supply, and end rods, then I can order the actuators...those will take a couple of days, local supplier.
  9. ledfoot

    ledfoot Member

    Joined:
    Sep 9, 2009
    Messages:
    369
    Occupation:
    IT Manager
    Location:
    Toronto, Canada
    Balance:
    20Coins
    Ratings:
    +2 / 0 / -0
    Cool. Hurry up and finish so you can join in on the fun :).
  10. johnfatboy

    johnfatboy New Member

    Joined:
    Sep 6, 2009
    Messages:
    34
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
    :clap: got my actuators


    boy do they look smaller then in pictures.


    should have my tie rods any time now :biw:

    Attached Files:

  11. Fahim

    Fahim Member

    Joined:
    Dec 11, 2008
    Messages:
    423
    Balance:
    249Coins
    Ratings:
    +1 / 0 / -0
    :) can't wait to see it all together.
  12. johnfatboy

    johnfatboy New Member

    Joined:
    Sep 6, 2009
    Messages:
    34
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
    almost...just been so busy with my racing and personal stuff. Hope by the end of the weekend... 8)
  13. johnfatboy

    johnfatboy New Member

    Joined:
    Sep 6, 2009
    Messages:
    34
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
    Finally completed it and took a spin around Watkins Glen with the Riley, i am also using the track ir but the screen is real bright...can't really see the track.

    http://www.youtube.com/watch?v=HoHisLQX23g

    http://s121.photobucket.com/albums/o229 ... 20cockpit/

    and some pics of my build

    was alot of work and glad to have help from a fellow member with the electrical :)
    thanks Ledfoot!

    there is alot of minor tweeking, I had it working for the Radical at Watkins yesterday and the experience is like nothing else...and today playing with the Riley, preparing for next season..i am fine tuning the profile.

    For info and instructions if you want to do something like this go to
    http://www.x-simulator.de/forum/
    also, here
    http://simxperience.com/

    I also want to thank my Wife for her support :) you gotta love our Sim Racing wives !!
  14. ledfoot

    ledfoot Member

    Joined:
    Sep 9, 2009
    Messages:
    369
    Occupation:
    IT Manager
    Location:
    Toronto, Canada
    Balance:
    20Coins
    Ratings:
    +2 / 0 / -0
    Nice Job John,

    Glad I was able to help you sort things out :).

    ....Mike
  15. Fahim

    Fahim Member

    Joined:
    Dec 11, 2008
    Messages:
    423
    Balance:
    249Coins
    Ratings:
    +1 / 0 / -0
    Nice video John. well done.
  16. audiojester

    audiojester New Member

    Joined:
    Oct 15, 2009
    Messages:
    29
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
    I just got my actuators the other day too! They DO look small compared to what I thought. Are you done building yet? I really wanna see how your playseat turned out. Just curious why you chose to go the playseat route also..
  17. ledfoot

    ledfoot Member

    Joined:
    Sep 9, 2009
    Messages:
    369
    Occupation:
    IT Manager
    Location:
    Toronto, Canada
    Balance:
    20Coins
    Ratings:
    +2 / 0 / -0
    I went the Playseat route as well because I already had it and the seat was comfortable enough for me. I also wanted to have a fully adjustable steering and pedal attachment since you cannot move the seat once the actuators are attached.

    See my post also for some pics of my setup for additional ideas as well
    http://www.x-simulator.de/forum/ledfoot-s-2dof-simulator-project-t1936.html

    ...Mike
  18. sn4il

    sn4il New Member

    Joined:
    Oct 26, 2009
    Messages:
    55
    Balance:
    2Coins
    Ratings:
    +1 / 0 / -0
    Great job man on the sim. Congrats!
    What kind of u-joint or ball joint did You use for the pivot on the seat?
    I'm starting my build next week, still gathering all the parts together :)
    sn4il
  19. audiojester

    audiojester New Member

    Joined:
    Oct 15, 2009
    Messages:
    29
    Balance:
    0Coins
    Ratings:
    +0 / 0 / -0
    I went to a Franks do it best Hardware store for a u-joint and a rod and a base that all fit together and it was amazingly easy (as long as you can hacksaw a steel rod) They have evvverrryyythinnggg!!!!

    Attached Files:
